High Light Transmission Heat Insulation PET Base Film

Product parameters

    • Appearance：Light blue transparent film
    • Transmittance of visible light：70%
    • Infrared barrier rate：≥90%
    • UV blocking rate（200~380nm)：＞99%
    • Fog：≤0.8%
    • Surface tension：52dyn/cm
    • Common thickness：23μm，36μm，50μm Etc.
    • Common width：1560mm，1040mm Etc.
    • Surface treatment：Single or double-sided corona, or pre-coating treatment

Product parameters

    • Appearance：Light blue transparent film
    • Transmittance of visible light：70%
    • Infrared barrier rate：≥95%
    • UV blocking rate（200~380nm)：＞99%
    • Fog：≤0.8%
    • Surface tension：52dyn/cm
    • Common thickness：23μm，36μm，50μm Etc.
    • Common width：1560mm，1040mm Etc.
    • Surface treatment：Single or double-sided corona, or pre-coating treatment

Product parameters

    • Appearance：Light blue transparent film
    • Transmittance of visible light：80%
    • Infrared barrier rate：≥80%
    • UV blocking rate（200~380nm)：＞99%
    • Fog：≤0.8%
    • Surface tension：52dyn/cm
    • Common thickness：23μm，36μm，50μm Etc.
    • Common width：1560mm，1040mm Etc.
    • Surface treatment：Single or double-sided corona, or pre-coating treatment
Reference price：
Add to shopping cart Buy

Functional Powder

Functional Dispersion Liquid

Functional Masterbatch

Functional Coatings

Functional Textile Finishing Agents

Functional Film

Functional Non-woven Fabric

Product Introduction

This product is made of environmentally-friendly anti-infrared polyester masterbatch pull film, has its own anti-infrared high insulation function, belongs to the raw material additive, non-coating. High definition, excellent anti-infrared heat insulation performance.

Product Features

High thermal insulation, infrared barrier rate as high as 80%~95%;
Good weather resistance,QUV3000h,does not fade,the heat insulation rate does not decay;
Good flatness, no crystal point, no precipitation, no orange peel;
Environmental Protection, does not contain toxic and harmful substances.

Usage method

Customers can according to their own product specifications, through coating, composite and other ways, processing into a variety of forms with thermal insulation infrared function of the product.

Uses

For the production of automotive film, building film, heat insulation and energy saving and anti-aging anti-ultraviolet effect;
For other UV, infrared blocking needs of the field.

Packaging and Storage

Packing: 1.56×4000m, with plywood hanging in the air (avoid touching and pressing) .
Storage: keep in a cool, dry place, away from direct sunlight.
