CQ-N20-W
G-P20-W

Water-based Nano GTO Dispersion Liquid

Product parameters

    • Appearance:Blue-black liquid
    • Active ingredient:Tungsten doped metal oxides
    • Primary particle size:40~50nm
    • Specific gravity:1.10
    • VLT+IRR,%165
    • Solid content:20%
    • pH7.0±0.5
    • Solvent:Water
    • Infrared blocking band:780~2500nm





Product parameters

    • Appearance:Blue-black liquid
    • Active ingredient:Tungsten doped metal oxides
    • Primary particle size:30~40nm
    • Specific gravity:1.12
    • VLT+IRR,%169
    • Solid content:20%
    • pH7.0±0.5
    • Solvent:Water
    • Infrared blocking band:780~2500nm
Reference price:

Functional Dispersion Liquid

Functional Masterbatch

Functional Coatings

Functional Textile Finishing Agents

Product Introduction

The product is an aqueous dispersion of GTO nano-thermal insulation powder, with the highest thermal sensitivity to human skin at around 1000nm near-infrared (Nir) , and a much higher barrier capacity than ATO and ITO. The glass insulating coating made of the dispersant can greatly improve the comfort of human body and provide a technical guarantee for creating a more comfortable, environment-friendly and energy-saving indoor environment.

Product Features

Small and uniform particles, good transparency, good compatibility;
It is superior to the ATO and Ito in blocking near-infrared rays at about 1000nm.
Strong weather resistance, QUV 5000h+ , non-fading, no change in performance;
Does not contain heavy metals, halogen and other toxic and harmful substances;
With independent intellectual property rights, with quality, price advantages, cost-effective.

Usage method

It is recommended to add 5%~20% in water-based resin system, and it can also be mixed with nano-sized pastes of ATO, Ito and other metal oxides to produce various forms of transparent heat insulation and infrared protection products.

Uses

For the production of environmentally friendly high-performance transparent glass insulation coating, or for other anti-infrared needs of the field.

Packaging and Storage

Packing: 20kg/barrel.
Storage: keep in a cool, dry place, away from direct sunlight.
